loganw.dev

Logan W.

19 (pins.json) commits pinned · GitHub snapshot 2026-09-29 (sources/github-2026-09-29-1621.json) · 1 of 9 (site/pages/) pages built · a figure whose source stops matching stops the build

I'm Logan. I have worked as a carpenter since I was fifteen, and I have no formal training in computing. AI agents have written essentially all of the code in these projects; gates decide what is true, and the record keeps what they said. (stated by Logan, 2026-09-29)

IWhere each project came from

Where each project came from: born dates across, threads down, typed relations between them DETERMINISM FILM & PHOTOGRAPHY PRESERVATION snapshot 2026-09-29 Nov 2025 Jul 2026 Aug Sep Oct 22 mercs2 repositories created 06-29 to 07-25 PrettyCloud grew into atlas-darkroom PrettyCloud grew into atlas-engine atlas-engine grew into cft-fp256 atlas-engine verifies cft-fp256 atlas-engine underlies atlas-darkroom atlas-darkroom spun out atlas-optical atlas-darkroom spun out atlas-film cft-fp256 underlies cft-rebound cft-fp256 underlies Quantum-Film atlas-film underlies Quantum-Film cft-fp256 hosts a port of atlas-film cft-rebound was distilled into ParcelRound cft-fp256 was distilled into HonestFramework Mercenaries2 grew into Merc2-Mods-Exp PrettyCloud atlas-engine cft-fp256 cft-rebound ParcelRound HonestFramework CanonBracketTool Microscope-Stacker atlas-darkroom private atlas-optical private atlas-film Quantum-Film Mercenaries2 server refesl.live Merc2-Mods-Exp
Across: the day each repository was born — its first commit at the pin, on its author's calendar; the date its README states it was split out of another; or, for a repository read only through the GitHub snapshot, its first commit there, in UTC. Down: the threads. Read each arrow as a sentence, tail to head; each one names the file that says so.
The file behind each arrow, and behind each position
  1. PrettyCloud grew into atlas-darkroom: A print engine for the Atlas of Mathematical Forms (atlas-darkroom c1b9b6e README.md:3, private for now)
  2. PrettyCloud grew into atlas-engine: Sixty-eight plates in PrettyCloud (atlas-engine 867c57a README.md:8)
  3. atlas-engine grew into cft-fp256: The workload this tile exists to serve is [atlas-engine] (cft-fp256 77b8440 README.md:421)
  4. atlas-engine verifies cft-fp256: A GPU agrees, bit for bit, on a real workload (cft-fp256 77b8440 README.md:232)
  5. atlas-engine underlies atlas-darkroom: presentation from PrettyCloud, shape from atlas-engine (atlas-darkroom c1b9b6e README.md:282, private for now)
  6. atlas-darkroom spun out atlas-optical: Extracted whole from atlas-darkroom on 2026-08-28 (atlas-optical dbccafe README.md:5, private for now)
  7. atlas-darkroom spun out atlas-film: Born 2026-08-28 by extraction from the darkroom's develop monolith (atlas-film be1d674 README.md:135)
  8. cft-fp256 underlies cft-rebound: REBOUND's IAS15 integrator with its arithmetic routed through libcft (cft-rebound 039e3c3 README.md:3)
  9. cft-fp256 underlies Quantum-Film: path = vendor/cft-fp256 (Quantum-Film a7f02db .gitmodules:2)
  10. atlas-film underlies Quantum-Film: path = vendor/atlas-film (Quantum-Film a7f02db .gitmodules:5)
  11. cft-fp256 hosts a port of atlas-film: P2 moves atlas-film (ParcelRound 8767e23 CASE-STUDY-4.md:28)
  12. cft-rebound was distilled into ParcelRound: lifted into a standalone repository (cft-rebound 039e3c3 docs/PARCEL-ROUNDS.md:13)
  13. cft-fp256 was distilled into HonestFramework: §1 bit-identity authority, §2 refusal, §3 the gates, §4 single-sourcing, §6 artifact manifests (HonestFramework 65447fd CASE-STUDY.md:18)
  14. Mercenaries2 grew into Merc2-Mods-Exp: For the mods developed during this phase of the project, visit [Merc2-Mods-Exp] (Mercenaries2 e51dcbe README.md:5)

Positions, earliest first:

Families:

  • 22 (GitHub snapshot 2026-09-29) mercs2 repositories, created 06-29 to 07-25 (GitHub snapshot 2026-09-29)

The rest of what the drawing marks:

  • the line marked "snapshot": 2026-09-29 (sources/github-2026-09-29-1621.json)
  • atlas-darkroom: private (GitHub snapshot 2026-09-29, private for now)
  • atlas-optical: private (GitHub snapshot 2026-09-29, private for now)
  • Mercenaries2: server refesl.live (Mercenaries2 e51dcbe README.md:145)

IILedger

projectwhat it isstatelast verifiedagent-creditedcheck it
Determinism
PrettyCloudA WebGL2 point-cloud atlas (PrettyCloud 5161daa README.md:3)served at prettycloud.io (PrettyCloud 5161daa README.md:12)— (PrettyCloud 5161daa)33/39 (PrettyCloud 5161daa git log)open it
atlas-engineA language for platonography (atlas-engine 867c57a README.md:3)Sixty-eight of sixty-eight, one hash (atlas-engine 867c57a README.md:176)2026-09-18 (GitHub snapshot 2026-09-29)70/84 (atlas-engine 867c57a git log)cft-fp256's photograph stage, a minute and a half (cft-fp256 77b8440 README.md:239)
cft-fp256A math coprocessor that gets the same answer everywhere (cft-fp256 77b8440 README.md:3)ABI 0.15 (cft-fp256 77b8440 host/include/cft.h:111) on main; a revision-7 round is under way off main (stated by Logan, 2026-09-29)2026-09-29 (GitHub snapshot 2026-09-29)1030/1079 (cft-fp256 77b8440 git log)make verify-quick, ~20 min, 28 of 41 stages (cft-fp256 77b8440 CLAUDE.md:9)
cft-reboundREBOUND's IAS15 integrator with its arithmetic routed through libcft (cft-rebound 039e3c3 README.md:3)At binary64 it is REBOUND's own IAS15 bit for bit (cft-rebound 039e3c3 README.md:22)2026-09-14 (cft-rebound 039e3c3 docs/VALIDATION.md:3511)130/136 (cft-rebound 039e3c3 git log)make check-quick, 5-second warm (cft-fp256 77b8440 CLAUDE.md:26)
binary-sitesFour sites, one per IEEE 754 binary interchange format (binary-sites dacdcb8 README.md:5, private for now)private (GitHub snapshot 2026-09-29, private for now) for now; binary32.com · binary64.com · binary128.com · binary256.com (binary-sites dacdcb8 README.md:3, private for now)2026-09-21 (GitHub snapshot 2026-09-29, private for now)6/6 (binary-sites dacdcb8 git log, private for now)—
nextpnr-xilinxa fork of openXC7's router, which does not converge on the tile (cft-fp256 77b8440 docs/README.md:118: “openXC7's router does not converge on the tile, what to change in it and in what order, and why a fork of it (loganw234/nextpnr-xilinx, dense) starts at the pinned 0.9.6”)listed, not covered here— (GitHub snapshot 2026-09-29)— (GitHub snapshot 2026-09-29)repository
ParcelRoundA method for splitting one body of work across several coding agents at once (ParcelRound 8767e23 README.md:3)4 (ParcelRound 8767e23 ls-tree) rounds recorded; METHOD.md last changed 2026-09-16 (ParcelRound 8767e23 git log -- METHOD.md)— (ParcelRound 8767e23)86/86 (ParcelRound 8767e23 git log)CASE-STUDY-4.md (ParcelRound 8767e23)
HonestFrameworkA way to lay out a project so that an AI can write nearly all of it and no claim about it ever rests on the AI's judgement (HonestFramework 65447fd README.md:3)ten (HonestFramework 65447fd README.md:38) mechanisms, and a gate of its own— (HonestFramework 65447fd)4/4 (HonestFramework 65447fd git log)python tools/check_claims.py
Film & photography
CanonBracketToolA python based webtool and sdk wrapper for interacting with the Canon SDK to create shot sequences easily and automate shooting. (GitHub snapshot 2026-09-29)a beginning project, from before the method (stated by Logan, 2026-09-29)— (GitHub snapshot 2026-09-29)0/9 (GitHub snapshot 2026-09-29)repository
Microscope-StackerA tool for stacking images captured on microscopes at various magnifications and exporting a final combined photo retaining detail at all magnifications in one image. (GitHub snapshot 2026-09-29)a beginning project, from before the method (stated by Logan, 2026-09-29)— (GitHub snapshot 2026-09-29)0/7 (GitHub snapshot 2026-09-29)repository
atlas-darkroomA print engine for the Atlas of Mathematical Forms (atlas-darkroom c1b9b6e README.md:3, private for now)private (GitHub snapshot 2026-09-29, private for now) for now2026-09-05 (GitHub snapshot 2026-09-29, private for now)1005/1156 (atlas-darkroom c1b9b6e git log, private for now)—
atlas-opticalThe glass of the Eidograph, on its own (atlas-optical dbccafe README.md:3, private for now)private (GitHub snapshot 2026-09-29, private for now) for now; spun out of atlas-darkroom 2026-08-28 (atlas-optical dbccafe README.md:6, private for now)2026-09-05 (GitHub snapshot 2026-09-29, private for now)91/91 (atlas-optical dbccafe git log, private for now)—
atlas-filmThe medium of the Eidograph (atlas-film be1d674 README.md:3)branch pinned at d4007b2 (ParcelRound 8767e23 CASE-STUDY-4.md:382), its merge left open (ParcelRound 8767e23 CASE-STUDY-4.md:388: “Whether atlas-film's pinned merges into its main”)2026-09-05 (GitHub snapshot 2026-09-29)74/74 (atlas-film be1d674 git log)PROVENANCE.md (atlas-film be1d674)
Quantum-FilmFilm stocks whose crystals are laid by quantum circuits (Quantum-Film a7f02db README.md:3)14 (Quantum-Film a7f02db verify/run.sh) runner stages2026-09-26 (Quantum-Film a7f02db docs/VALIDATION.md:1026)60/60 (Quantum-Film a7f02db git log)The web demo (Quantum-Film a7f02db README.md:74)
Preservation
Mercenaries2A revival project for Mercenaries 2: World in Flames (Mercenaries2 e51dcbe README.md:9)online play through refesl.live (Mercenaries2 e51dcbe README.md:145)— (Mercenaries2 e51dcbe)20/46 (Mercenaries2 e51dcbe git log)README.md (Mercenaries2 e51dcbe)
mercs2-lua-essentialsEss, the foundational Lua library for Mercenaries 2 modding (mercs2-lua-essentials 3430c0b README.md:3)one of 22 (GitHub snapshot 2026-09-29) public mercs2 repositories2026-08-04 (GitHub snapshot 2026-09-29)188/211 (mercs2-lua-essentials 3430c0b git log)repository

Each figure names where it was read: a repository at the commit in the footer, or the GitHub snapshot. Last verified: the newest recorded pass of the repository's own gate at or before its pin, on its author's calendar — a run of a workflow pins.json classes as verifying, on the pinned commit or an ancestor of it, or a ledger line in a form pins.json declares as a pass; a dash means neither records one. Agent-credited: commits with a Co-Authored-By line naming Claude or Gemini, of all its commits — a trailer, not a line count, and a lower bound: Logan's word is that every project here was AI-driven, and the co-author line was not always added to its commits (stated by Logan, 2026-09-29).

IIICheck it yourself

Don't trust this page.

  1. cft-fp256's web page replays the published conformance vectors in front of you (cft-fp256 77b8440 README.md:30). Nothing to install.
  2. make golden in a clone of cft-fp256: The golden model's self-tests (cft-fp256 77b8440 README.md:254).
  3. make verify-quick: ~20 min, 28 of 41 stages (cft-fp256 77b8440 CLAUDE.md:9).
  4. python site/build.py --verify-facts in a clone of this site: every figure on this page read again, from its repository at its pin or from the committed GitHub snapshot. One read at a private repository's pin is skipped by name, and a stated one has no source to read.

IVThe film thread

The Pauli print
Pauli
The Poisson print
Poisson
The TRI-X print
TRI-X

Pauli, its Poisson twin and TRI-X (Quantum-Film a7f02db README.md:30), as Quantum-Film's commit e7935ef (Quantum-Film a7f02db git log -- docs/prints/pauli-print.png) laid them. Every print re-developed to the same bits (ParcelRound 8767e23 CASE-STUDY-4.md:213) when checked.

VNot here
